Truck Mounted Drilling Rig with 1000 meters Capacity
Açıklama :
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua.
Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.
Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur.
Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum.
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua.
Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.
Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur.
Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum.
| TECHNICAL SPECIFICATIONS | |||
| TOWER | Pole Pipes Thickness:100*100 6mm profile | TOWER DIMENSIONS | 1) Length :14 meters 2) Back Width: 1.80 meters 3) Height:1.00 meters 4) Mast Height from Ground: 16-17 meters |
| GÜVERTE MOTOR | 1) One diesel engine mounted on the deck 2) Deck Engine422hp MAN 3) Deck Engine Turbo Intercooler 4) Engine Gearbox 85 ZF and Clutch Plate Diameter 42 cm 5) Deck Engine overhauled |
TRANSFER BODIES | 1) Chain Transfer Box 2) There is ZF 85 transmission in the transfer case and the Clutch Plate diameter is 42 cm 3) There Are 5 Outputs in the Transfer Box 4) The chain of the Transfer Box is 4 rows 5) The gear in the Transfer Box is 5 pieces and 4 rows 6) Shafts MAN (Made in Germany) 7) Total number of shafts 3 pcs |
| ROPE WINDERS DRUM | 1) Two Sided One Piece Rope Winder 2) Drum diameter 800 mm 3) Brake diameter 800mm 4) Each Drum Has 5 Clutch Pads. |
DÖNER ROTARY | 1) ROTARY -Internal; Diameter: 240mm -Turning Diameter: 650mm -External Diameter: 1000mm 2) Revolving Table Height from the ground 160 cm-220 cm (max) 3) Revolving Table embedded for bottom and top Covers; keçe 4) heavy content and |
| KELLY | 1) Kelly. 2) Kelly groove 3’’ 3) kelly &Cedil;steel is made 4) Kelly 4 or 6 corners. 5) Kelly length is 11 meters width is 130mm-135mm 6) Pulleys Kelly has 4 pulleys and 8 rows of rope. 7) Service pulley has 2 pulleys and 4 rows of rope. |
CIRCULATION SYSTEM |
1) One-piece Centrifugal Pump mounted on the machine |
| HYDRAULIC SYSTEM | 1) Number of machine stabilizer feet 4 pcs 2) Stabilizers are double-footed and reciprocating 3) There are 2 pistons for the machine tower 4) There are 2 pistons for Rotary back and forth 5) Hydraulic pump Volume is 80 liters and hoses are 2-wire |
ELECTRICAL SYSTEM | 1) Total number of Lightning Projectors is 5 and Lightning Distance is 25 meters(lighting) 2) Control Panel Engine Start & There will be a Stop Button, a heat and oil gauge. |
| ROOLS AND ROPES SYSTEM | 1) Roller diameter 32 and 26 cm 2) Total number of reels 20 pcs 3) Rope diameter 20 mm 4) Total Rope length is about 250 meters |
HELPER PARÇALAR | 1) One-piece Manual Tong 2) One-piece Pipe-Vise 3) One-piece Lifting hook 4) One Piece service hook |
| ACCESSORIES AND PAINTING | 1) Walking Platform along both sides 2) One-piece Engine Cabin 3) Acrylic Seawater Resistant Paint 4) Machine color is according to buyer's request |
||
